◆ Directly Connected to 1000, 1500 Vdc
◆ flexiable input by external shunts or sensors:
◆ ± 50mV/ ± 75mV standard signal inputs
◆ Wide Operating Range: -40~70 °C
◆ Accuracy: 0.5 IEC 62053-41-2021
◆ CE, UL Certificate
| Parameter | Accuracy | Resolution | Range |
| Voltage(U) | 0.2% | 0.1 V | Nominal Voltage:1000V/1500V DC Measurement Range:0.1 Un~1.15 Un |
| Current(1) | 0.2% | 0.01 A | Shunt or Hall ffect Sensor Indirect Connection Program:0～50000A |
| Power(P) | 0.5% | 0.1 kW | |
| Energy(E) | IEC62053-41 class 0.5 EN50470-4 class C(0.5) ANSI C12.32 class C(0.5) |
0.0001 kWh | >99999999.9kWh |
| Ampere-Hour(Ah) | 0.5% | 0.1 Ah | >99999999.9Ah |
| Real Time Clock | 0.5 s/d | - | - |
|
Metering Voltage Current Power Ampere-Hour Energy and Energy Record Bi-Directional Energy 12 Monthly Energy Record Demand Power and Current Demand Peak Demand Record |
Time of Use (TOU) Four Tariffs, 12 Seasons, 14 Schedules Two TOU Settings can Automatically Switch at the Setting Time 12 Monthly TOU Energy Record Reduce Electricity Theft Design Terminal Cover Sealing Metrology Seal
|
